Siemens 6ES7231-5PA30-0XB0

SIMATIC S7-1200, Analog input, SB 1231RTD, 1 AI RTD, Pt100 and Pt1000

General information
Product type designation SB 1231, AI 1x16 bit RTD
Supply voltage
Rated value (DC) 24 V
Input current
Current consumption, typ. 5 mA
from backplane bus 5 V DC, typ. 20 mA
Power loss
Power loss, typ. 0.5 W
Analog inputs
Number of analog inputs 1; Resistance thermometer
permissible input voltage for current input (destruction limit), max. ±35 V
Technical unit for temperature measurement adjustable Degrees Celsius/degrees Fahrenheit
Input ranges
● Voltage Yes
● Current No
● Thermocouple No
● Resistance thermometer Yes; Platinum (Pt)
● Resistance Yes; 150 Ω, 300 Ω, 600 Ω
Input ranges (rated values), voltages
● -80 mV to +80 mV
— Input resistance (-80 mV to +80 mV) >= 10 MOhm
Input ranges (rated values), resistance thermometer
● Pt 100 Yes
— Input resistance (Pt 100) 100 Ω
● Pt 1000 Yes
— Input resistance (Pt 1000) 1 000 Ω
● Pt 200 Yes
— Input resistance (Pt 200) 200 Ω
● Pt 500 Yes
— Input resistance (Pt 500) 500 Ω
Input ranges (rated values), resistors
● 0 to 150 ohms Yes
● 0 to 300 ohms Yes
● 0 to 600 ohms Yes
Thermocouple (TC)
Temperature compensation
— parameterizable No
Analog outputs
Number of analog outputs 0
Cable length
● shielded, max. 100 m; shielded, twisted pair
Analog value generation for the inputs
Measurement principle integrating
Integration and conversion time/resolution per channel
● Resolution with overrange (bit including sign), max. 15 bit; + sign
● Integration time, parameterizable No
● Interference voltage suppression for interference frequency f1 in Hz 85 dB at 10 / 50 / 60 / 400 Hz
Errors/accuracies
Temperature error (relative to input range), (+/-) 25 °C ±0.1%, to 55 °C ±0.2% total measurement range
Repeat accuracy in steady state at 25 °C (relative to output range), (+/-) 0.05 %
Interference voltage suppression for f = n x (f1 +/- 1 %), f1 = interference frequency
● Common mode interference, min. 120 dB
